JL7 High-quality Slewing Drive

JL7 High-quality Slewing Drive

JL7 Series Products have been using in many projects for years, great response received.

  • Product Origin:

  • Item NO.:

  • Shipping Port:

  • Color:

    Customer wants
  • Payment:

Product Detail

Slew Drive Capability (JL7-537)

Ratio of Worm Gear


Tracking Precision


IP Class



-30 ~ +70°C

Holding torque


Axial Static Load

48 kN

Axial Dynamic Load

26 kN

Radial Static Load

87 kN

Radial Dynamic Load

45.8 kN

Tilting Moment Torque



Planetary Reducer Motor Performance Data24/90/80

Rated Voltag


Rated Current


Gear Ratio


IP Class





       Slew Drive Performance Data (JL7+24/90/80)

Nominal output speed

0.0167 rpm

Nominal output torque

10 kN.m

output torque (JL7)

Output Speed (JL7)

Efficiency    (only JL7)

Motor Current (24/90/80)

Nominal torque: 10KN.m Continuous operation Most operating conditions

0.0167 rpm



Large torque: 15KN.m     Continuous operation for 10 minute  It should not exceed 5% of the total

0.016 rpm



Limit torque: 20 KN.m    Continuous operation for 2 minute   Should be rare

0.015 rpm



Warning: There is no safety factor
